NOMEX FIBER GLASS PANELS

FST Epoxy Fiberglass Prepreg / NOMEX Core Panels

Our Low Heat Release/FST Epoxy Fiberglass Prepreg / NOMEX Core panels offer high
strength and lightweight solutions for a variety of applications.

Various applications include:

  • Composite Laminates in need of excellent surface finish ready for paint
  • Aircraft Interior Laminates or Sandwich Structures requiring OSU/FST Performance
  • Aircraft Interior Ducting
  • Composite Laminates requiring low porosity and low toxicity
  • Aircraft Interior Floorboards, Ceiling Panels, Sidewalls and Bulkheads



Various ply orientation, count and CORE call outs can be quoted as well to fit your specific
design. Panels can also be cut to size or various shapes based on your design. Edge-fill
and potted inserts can also be applied per your request.

Various finishes are also offered to match your current design or build to print specifications.
ACMFG also offers just in time inventory for high volume blanket purchase orders to ensure
we meet your high demand release dates.

Epoxy Fiberglass Skin
NOMEX Core – Aerospace Composite Panel

Skins 0.020” Epoxy Fiberglass
Core NOMEX 1/4” Cell Size, 3.0 lbs/ft³
Adhesive Low Heat Release / FST Epoxy Fiberglass Prepreg
Standard Dimensional Length & Width: ±0.500”
Tolerances Thickness: ±0.010”
Panel Dimension 48” x 96” (up to 60” x 144”)



Panel Part # Panel Thickness Panel Weight Core Sheet Thickness
inches lbs/sf Inches
ACM-0125-G2-3180-N1019 0.125 0.47 0.085
ACM-0250-G2-3180-N1019 0.250 0.50 0.210
ACM-0500-G2-3180-N1019 0.500 0.57 0.460
ACM-0625-G2-3180-N1019 0.750 0.63 0.710
ACM-01000-G2-3180-N1019 1.000 0.69 0.960
